69
Step 1 To access the FOOT SW MAPPING function, turn the FUNCTION SELECT knob clockwise
to "FOOT SW MAPPING".
The "FOOT SW MAPPING" function allows you to select what effect will be used in the 2ND
FUNCTION MODE when accessing the EFFECT ON/OFF (Second Function button number 1)
EFFECT ON/OFF - turns on or off the assigned effect to that footswitch, either Bypass, Toggle, Solo,
Compressor, Modulation Effect, Delay, Reverb Input or Tru-Bypass (one must be set & stored in the
Footswitch Mapping Function).
Bypass Effect bypass - turns on or off all the effects and bypasses them completely.
Toggle Channel Toggle - allows you to toggle between two different channels (for ex
ample, between Deep nd DIST)
SOLO Solo Boost - allows a 4db boost in output, ideal to get a boost when soloing
Compressor Turns on and off the Compressor within the preset.
MOD EFX Turns whatever Modulation Effect (Chorus, Pitch Shift, Flanger, Tremolo) you
have assigned on or off.
Delay Turns on and off the Delay within the preset
Reverb Input Turns on and off the Reverb (Active or Muted)
TBypass Tru-Bypass - turns on and off the effects and preamp and allows the signal to pass
through the B200 unaffected.
8. Foot SW Mapping (Footswitch Mapping)
F o o t s w m a p p i n g
e f x 1 b y p a s s
2, 3,5 6 4 1
Step 2 Use the PARAMETER ADJUST knob to select Bypass, Toggle, Solo, Compressor, Modula-
tion Effect (either Chorus, Flanger, Pitch Shift or Tremolo) , TBypass (Tru-Bypass).
f o o t s w m a p p i n g
e f x 1 s o l o
