44
FUNCTION PARAMETER LIST RANGE
(via FUNCTION SELECT) (via PARAMETER SELECT) (via PARAMETER ADJUST)
MODULATION MODULATION EFX Chorus, Flanger, Tremolo
EFX Pitch Shift
CHORUS CHORUS (Chorus In/Out Status) Out, In
LEVEL 1 (Voice 1 Level) OFF to +4(dB)
PAN 1 (Voice 1 Panning) L <0 to 100> R
DEPTH 1 (Voice 1 Modulation Depth) 0 to 100
RATE 1 (Voice 1 Modulation Rate) 0 to 254
DELAY 1 (Voice 1 Delay Length) 2ms to 40ms
LEVEL 2 (Voice 2 Level) OFF to +4(dB)
PAN 2 (Voice 2 Panning) L <0 to 100> R
DEPTH 2 (Voice 2 Modulation Depth) 0 to 100
RATE 2 (Voice 2 Modulation Rate) 0 to 254
DELAY 2 (Voice 2 Delay Length) 2ms to 40ms
FLANGER FLANGER (Flanger In/Out Status) Out, In
LEVEL 1 (Voice 1 Level) OFF to +4(dB)
PAN 1 (Voice 1 Panning) L <0 to 100> R
DEPTH 1 (Voice 1 Modulation Depth) 0 to 100
RATE 1 (Voice 1 Modulation Rate) 0 to 254
LEVEL 2 (Voice 2 Level) OFF to +4(dB)
PAN 2 (Voice 2 Panning) L <0 to 100> R
DEPTH 2 (Voice 2 Modulation Depth) 0 to 100
RATE 2 (Voice 2 Modulation Rate) 0 to 254
REGEN (Flanger Regeneration Level) OFF to +4(dB)
TREMOLO TREMOLO (Tremolo In/Out Status) Out, In
LOCATION (Pre or Post Reverb Location) Pre-Rev, Post-Rev
DEPTH (Modulation Depth) 0 to 100
T-RATE (Tremolo Modulation Rate) 0 to 254
SHAPE (Wave Shape) Triangle, Square
PITCH SHIFT PITCH SHIFT (Pitch Shift In/Out Status) Out, In
LEVEL (Pitch Shift Signal Level) OFF to +4(dB)
PAN (Pitch Shift Signal Panning) L <0 to 100> R
PITCH (Pitch Shift in 20-Cent Steps) -2400 to +1200
FINE (Pitch Shift in 1-Cent Steps) -20 to +20
SPEED (Pitch Shift Signal Speed) Slow, Medium, Fast
DELAY DELAY (Delay Status) Muted, Active
MUTE TYPE (Mute Type Status) Pre, Post, Both
DELAY LVL (Delay Level) OFF to +4(dB)
MIX (Source 1/Source 2 Mix Level) S1 <0 to 100> S2
SOURCE 2 (Source 2 Select) DIRECT, Voice 2
DLY HF DAMP (Delay High Frequency Damping) 0 to 99
OUT LEVEL 1 (Delay 1 Level) OFF to +4(dB)
PAN 1 (Delay 1 Panning) L <0 to 100> R
DLY TIME1 (Delay 1 Length) 0 to 2000ms
REGEN 1 (Delay 1 Regeneration) OFF to +4(dB)
OUT LEVEL 2 (Delay 2 Level) OFF to +4(dB)
PAN 2 (Delay 2 Panning) L <0 to 100> R
DLY TIME2 (Delay 2 Length) 0 to 2000ms
REGEN 2 (Delay 2 Regeneration) OFF to +4(dB)
7. Function - Parameter - Range List continued.....
