Rocktron UTOPIA G300 User Manual

Page 12

23 PRE-EFFECTS (mono) LOOP SEND jack

Use this jack to send the signal from the G300 to the input of an outboard effect such as a

Rocktron Xpression or your favorite stomp box.

24 PRE-EFFECTS (mono) LOOP RETURN jack

Use this jack to receive the signal back from the output of the outboard effect or stomp box.

25 INPUT jack

This standard, mono 1/4" jack is used to provide input to the unit.

26 OUTPUT RIGHT jack

This 1/4" jack provides the right output of the UTOPIA G300 for use in stereo situations, such as

direct recording, plugging into a PA system, two Guitar ampliﬁers, etc.

27 OUTPUT LEFT/MONO jack

This 1/4" jack provides the left output of the UTOPIA G300. This output is a MONO output and

should be used in mono situations, such as plugging into the front of an ampliﬁer. For stereo

situations you must also use the OUTPUT RIGHT Jack.

28 AUX INPUT Jack

This 1/8" stereo jack provides an auxiliary input allowing you to plug a MP3 Player, CD Player,

etc. so that you can jam along with your favorite tunes.

29 PHONES jack

This 1/8” stereo jack provides a stereo output allowing you to practice in private. Note that you

need to activate the “STEREO” parameter in the GLOBAL Function in order to have a stereo

sound. Additionally, it is recommended that you set the Speaker Simulator in the GLOBAL

Function to “LOCK BOTH” as well. Note, this setting will be used until you turn OFF the

UTOPIA G300. The SPEAKER Simulator setting used in each preset may be modiﬁed per preset

while in this mode. See page 25 for more information on the GLOBAL Function. Note: Make

sure if you edit a preset and plan to store it to turn the SPEAKER SIMULATOR off if you do

not desire to store its current status. All global parameters will be stored during the preset storing

process.

30 USB jack

This standard USB jack allows you to connect to a computer for direct recording and

playback.

31 MIDI IN jack

This *7-pin DIN connector receives MIDI information from the device which is transmit-

ting the MIDI commands for the G300 to execute.

32 MIDI OUT/THRU jack

This *7-pin DIN connector passes on the MIDI information that is received at the MIDI IN

jack to other MlDI-compatible devices via a MIDI cable. It also outputs MIDI data when

performing a memory dump.

*Note a standard 5-pin MIDI cable may be used.

UTOPIA G300 Top and Back Panels....continued.....
