Rocktron UTOPIA G300 User Manual

Page 11

16 PRESET button 5

This button allows you to select presets 5, 15, 25, 35, 45, 55, 65, 75, 85, 95, 105, 115 and 125.

When you are in Bank 00 this button allows you to select preset 5. When you are in Bank 01 this

button allows you to select preset 15 and so on. Pressing this button a second time allows you to

enter into the 2nd Function mode for this preset. You can then use this button to turn On/Off the

EFFECT BYPASS on the preset selected.

17 PRESET button 6

This button allows you to select presets 6, 16, 26, 36, 46, 56, 66, 76, 86, 96, 106, 116 and 126.

When you are in Bank 00 this button allows you to select preset 6. When you are in Bank 01 this

button allows you to select preset 16 and so on. Pressing this button a second time allows you to

enter into the 2nd Function mode for this preset. You can then use this button to turn On/Off the

CHANNEL TOGGLE on the preset selected.

18 PRESET button 7

This button allows you to select presets 7, 17, 27, 37, 47, 57, 67, 77, 87, 97, 107, 117 and 127.

When you are in Bank 00 this button allows you to select preset 7. When you are in Bank 01 this

button allows you to select preset 17 and so on. Pressing this button a second time allows you to

enter into the 2nd Function mode for this preset. You can then use this button to turn On/Off the

a pre-assigned EFFECT on the preset selected.

19 PRESET button 8

This button allows you to select presets 8, 18, 28, 38, 48, 58, 68, 78, 88, 98, 108, 118 and 128.

When you are in Bank 00 this button allows you to select preset 8. When you are in Bank 01 this

button allows you to select preset 18 and so on. Pressing this button a second time allows you

to enter into the 2nd Function mode for this preset. You can then use this button to activate the

EFFECTS LOOP I/O (In/Out)

20 PRESET button 9

This button allows you to select presets 9, 19, 29, 39, 49, 59, 69, 79, 89, 99, 109, and 119 (note

there is no preset 129). When you are in Bank 00 this button allows you to select preset 9.

When you are in Bank 01 this button allows you to select preset 19 and so on. Pressing this but-

ton a second time allows you to enter into the 2nd Function mode for this preset. You can then

must use this button to exit the 2nd Function mode.

21 EXPRESSION PEDAL switch

To activate the Expression pedal, apply pressure to the toe of the expression pedal until this

switch is activated. You will know the pedal is active as you should be able to feel the switch

activate, but if not, the PEDAL ACTIVE LED will light when the switch is turned ON.

22 EXPRESSION PEDAL Jack

You can add an additional expression pedal or footswitch to the G300 using this jack and a RTS

¼ jack [stereo] cable. You can assign any parameter in the G300 to be adjusted by this pedal. We

recommend the following (sold separately) Rocktron Utopia Expression pedal, Rocktron HEX

Pedal or Rocktron VSF1 Footswitch.

UTOPIA G300 Top and Back Panels....continued.....
