Rocktron Xpression User Manual

Page 49

Text mode
Original mode

Operating the Xpression

™

Step 12

Step 13

Use the PARAMETER ADJUST control to select the lowest value which the parameter is not
to fall below through MIDI control changes.

Selecting a lower limit value that is greater than the upper limit value will invert the response
of the controller - i.e. the toe position of the expression controller will provide the minimum
value, while the heel position will provide the maximum value.

Note:

Steps 1-13 can be repeated nine times for a total of 10 controllers. To exit Con-
troller Assign at any time, turn either the PRESET or FUNCTION SELECT
control. Only those changes that have been stored will be saved after exiting the
Controller Assign function.

After selecting a value for the lower limit, press the STORE button to save it. "STORED" will
flash briefly on the display.

LLIM A

-12

STORED
