Remy 22SI All Replaceable Components 10539632 User Manual
Remy Generators
This manual is related to the following products:
Table of contents
Document Outline
- 21SI™ & 22SI™ HD ALTERNATOR REPLACEMENT COMPONENTS INSTRUCTIONS
- NOTE: Some components can be removed without following all steps as sequenced.
- NOTICE!!! It is recommended the DE and SRE bearings be replaced when replacing the rotor assembly.
- 4. If replacing DE frame (with bearing), dispose of it and press rotor assembly and spacer into replacement DE frame (with bearing).
- 6. Reinstall or replace the bearing retainer plate and screws. Torque the three (3) retainer screws to 4.5 - 5.7 Nm (40 - 50 lb in).
- 7. Go to component assembly instructions, page 2.
- The regulator and rectifier terminals are labeled to better enable following instructions for replacing components and parts.
- NOTE: Some components can be removed without following all steps as sequenced.
- 1. Remove the DE frame and rotor assembly, by removing the four (4) thru-bolts (mark end frames for reassembly) that hold the end frames together and separate the end frames.
- 21SI™ & 22SI™ SERVICE PARTS
