Specifi cations
Acoustic
Principle: Pressure gradient
Directional
Pattern: Cardioid (see graph)
Frequency
Range: 40Hz-20kHz, selectable HPF @
80Hz/12dB/octave (see graph)
Output
Impedence: 200
Sensitivity: -37 dB re 1 Volt/Pascal (16 mV @
94 dB SPL) +/- 2 dB @ 1kHz
Equivalent Noise: 19 dB SPL (A - weighted per
IEC651)
Maximum
Output: +6dBu (@ 1kHz, 1% THD into
1K load)
Dynamic Range: 119 dB (per IEC651, IEC268-15)
Maximum SPL: 135dB SPL
(@ 1kHz, 1% THD into 1K load)
(145dB with maximum PAD)
Signal/Noise: 75 dB SPL
(A - weighted per IEC651)
Power
Requirement: P48 (48V), P24 (24V) phantom
supply
Output
Connection: 3 pin XLR, balanced output
between pin 2(+), pin (-) & pin 1
(ground)
Net Weight: 386gm
