RODE Microphones Stereo VideoMic X - Manual (Page 4)

6 7
Specifications
Acoustic Principle Pressure Gradient
Polar Pattern Cardioid
Frequency Range 40Hz ~ 20kHz
Frequency Range (High
Pass Filter)
0, 75, 150Hz
Variable Level -10, 0, +20dB
Output Impedence 200Ω
Signal to Noise Ratio 82 dBA SPL (as per IEC651)
Equivalent Noise 12 dBA SPL (as per IEC651)
Maximum SPL 143dB SPL
Sensitivity -32 dB re 1V/Pa (25mV @ 94dB SPL) ±
2dB @ 1kHz
Dynamic Range 131 dB SPL
Power requirements 9V alkaline battery
Output Connection 3.5 Stereo mini jack plug (dual mono),
Tip – left channel, Ring – right channel,
Dual Mini XLR output (P48 compatible)
Battery Life 30 hours
Weight (No Battery) 300g
Dimension (W x L x H) 102mm x 118mm x 100mm
