Compact Mini Bench Top Reactors
w w w . p a r r i n s t . c o m 17
Reaction Vessel Parts List
Consult the itemized list for your reactor provided
along with this manual. For purpose of reactor identifi-
cation the following abbreviation/codes are used:
OR – O-ring FG – Flat Gasket
SS – T316 Stainless Steel SP – Special Alloy
* For parts made from alternate materials use the
codes shown below as a suffix to the standard part
number.
CM - Alloy 400 CC - Alloy 20Cb3
CT - Alloy 600 CA - Titanium G2 or G4
CG - Alloy B-2 CX - Zirconium
CH - Alloy C-276
Cylinder*
Part No. Description Code
452HC Cylinder 300 mL FG
452HC2 Cylinder 450 mL FG
452HC3 Cylinder 600 mL FG
452HC8 Cylinder 100 mL FG
452HC9 Cylinder 160 mL FG
2342HC Cylinder 300 mL OR
2342HC2 Cylinder 450 mL OR
2342HC3 Cylinder 600 mL OR
2342HC4 Cylinder 100 mL OR
2342HC5 Cylinder 160 mL OR
Heads*
Part No. Description Code
818HC Head, for thermocouple FG
818HC2* Head, for thermowell FG
2340HC Head, for thermocouple OR
2340HC2* Head, for thermowell OR
Internal Fittings*
Dip Tubes
Part No. Description Code
832HC Dip Tube for 300 mL SS
832HC4* Dip Tube with nut, 300 mL SP
832HC2 Dip Tube, 450 mL SS
832HC5* Dip Tube with nut, 450 mL SP
832HC3 Dip Tube, 600 mL SS
832HC6* Dip Tube with nut, 600 mL SP
832HC19* Dip Tube with nut,
100 mL/160 mL
SS/SP
* Denotes Special Materials Available
Male Connectors
Part No. Description Code
A833HC Male Connector, T/C,
1/8 NPTM x 1/8T SS
A834HC Male Connector, Cooling Coil,
1/8 NPTM x 3/16T SS
A92HW* Male Connector, Cooling Coil,
1/8 NPTM x 1/4T SS
A138CA Male Connector,1/8 NPTM X
1/4T Thermowell SP
Cooling Loop
Part No. Description Code
831HC Cooling Loop for 300 mL SS
831HC6* Cooling Loop for 300 mL SP
831HC2 Cooling Loop for 450 mL SS
831HC7* Cooling Loop for 450 mL SP
831HC3 Cooling Loop for 600 mL SS
831HC8* Cooling Loop for 600 mL SP
Stirrer Support Bracket
(450 mL and 600 mL only)
Part No. Description Code
A1260HC Stirrer Bracket w/o bushing SS
A1260HC2* Stirrer Bracket w/o bushing SP
1261HC Stirrer Bracket Bushing
Stirrer Shafts*
Part No. Description
822HC15 Shaft, 300 mL
822HC16 Shaft, 450 mL
822HC17 Shaft, 600 mL
822HC18 Shaft, 100 mL
822HC18 Shaft, 160 mL
