- 24 -
4570 HP/HT Pressure Reactors Parr Instrument Company
Overarm Parts List
Part No. Description
Motor
A388E6 Air Motor
A388EES Motor ¼ HP VS 90 VDC
A388E2ES Motor ½ HP VS 90 VDC
A388EEQ Motor ¼ HP EXP VS 90 VDC
A388E2EQ Motor ½ HP EXP VS 90 VDC
A388E2ER Motor ½ HP EXP VS 180 VDC
A388E2ET Motor ½ HP VS 180 VDC
A388EER Motor ¼ HP EXP VS 180 VDC
A388EET Motor ¼ HP VS 180 VDC
Driven Pulley Assembly
A2519HC
Driven Pulley Assembly consist of:
706HC2 Pulley, Driven
725HC Support Hub
730HC Ball Bearing
731HC Snap Ring Internal 2”
732HC Snap Ring External 1”
2429HC Bushing PTFE
Release Knobs
726HC
Release Knob, .50 Shaft
Part No. Description Code
Upper Drive Shafts
A2564HC Upper Drive Shaft 11.27” FHLD
A2564HC2 Upper Drive Shaft 7.64” FHHD
A2564HC4 Upper Shaft 6.32" FH(HD)(FMD)
A2564HC6 Upper Shaft 10.50" FH(LD)
A2564HC9 Upper Shaft 9.16" FH(LD)FMD)
A742HC13 Upper Shaft 8" RV(LD)(FMD)
A742HC14 Upper Drive Shaft 9.82” RVLD
A742HC17 Upper Shaft 5.8" RV(HD)(FMD)
Shaft Couplings
A722HC Shaft Coupling .50 RV
2352HC Shaft Coupling .50 FH
Drive
Pulleys (Motor) RV-Belt FH-Belt
695HC5 800 RPM 728HC 728HC5
695HC3 1000 RPM 728HC 728HC5
695HC2 1700 RPM 728HC3 728HC6
Optional Tach Parts
1564HC Optical Wheel
A1001E Tach Sensor Assembly (9.0”L)
