Parr Instrument Series 4570 User Manual
Page 2
- 2 -
4570 HP/HT Pressure Reactors
Parr Instrument Company
TABLE OF CONTENTS
Related
Instructions.......................2
Customer
Service..........................2
Preface...............................................3
Scope ............................................3
Safety
Information .........................3
General
Specifications ..................3
Explanation
of Symbols.................4
Environmental
Conditions .............4
Provisions for Lifting and
Carrying.........................................4
Intended
Usage .............................5
User’s
Responsibility .....................5
Unpack
Carefully ...........................5
Installation.........................................6
Pressure and Temperature
Limits.............................................6
Assemble the Reactor ......................7
Identify the Valves ............................10
Gas
Inlet
Valve ..............................10
Gas Release Valve........................10
Liquid Sampling Valve...................10
Other Vessel Head Fittings ..............11
Safety
Rupture Discs.....................11
Type J Thermocouple....................11
Pressure Gage ..............................11
Gage and Valve Adapters .............11
How to Use the Vessel .....................12
Fixed
Head
Vessels ......................12
Removable
Head Vessels .............12
Accessories ......................................14
Internal
Cooling Coil ......................14
Liners ............................................14
Spare
Parts Kits ............................14
Variable Speed Electric Motor .......14
Air
Motor........................................15
Pneumatic Lift for Fixed
Head
Vessels ................................16
Explosion Proof Operation.............. 17
Periodic Pressure Tests .................. 18
General Maintenance Notes ............ 19
Reaction Vessel Parts List .............. 20
Reaction
Vessel
Parts List ............ 20
Overarm
Parts List ........................ 24
Vessel Heater Stand & Parts List.. 26
4570 Vessel Stand Parts List ........ 27
Related Instructions
The following Parr publications are also
available to further your understanding of
this instrument and its component parts:
No. Description
230M Safety Precautions to be observed
when operating Pressure Reaction
Equipment
231M Operating Instructions for Parr Safety
Rupture Discs
234M Operating and Maintenance
Instructions for Parr Magnetic Drives
323M Operating Instructions for Parr
Pressure Relief Valves
548M Operating Instructions for 4848
Reactor Controllers
201M Limited Warranty
F0042 Health & Safety Assurance
Certification
Customer Service
Questions concerning the installation or
operation of this instrument can be
answered by the Parr Customer Service
Department:
309-762-7716
800-872-7720
Fax:
309-762-9453
www.parrinst.com
[email protected]
