- 21 -
4570 HP/HT Pressure Reactors Parr Instrument Company
Part No. Description Code
Stirrer Shafts* - Standard one piece
A1120HC (LD) / A1180HC (HD)
1323HC 1L, 9.50” RV(LD)
1323HC6 1.8 L, 13.88” RV(LD)
1323HC14 1L, 11.82” FH(LD)
1323HC15 1.8 L, 16.13” FH(LD)
1409HC12 1L, 12.25” FH(HD)
1409HC13 1.8 L, 16.56” FH(HD)
1409HC 1L, 9.84” RV(HD)
1409HC2 1.8 L, 14.15” RV(HD)
Gas Entrainment Stub Shaft (Upper)
1323HC13 4.16” MV(LD)
1323HC16 6.43” FH(LD)
2128HC 4.62” MV(HD)
2128HC5 6.94” FH(HD)
Gas Entrainment Lower Shaft
2062HC9 1L, 3.4” LD/HD
2062HC10 1.8L, 6.64” LD/HD
Stirrer Shafts Footless Magnetic Drive
A2150HC (LD) / A2160HC (HD)
2141HC33 1L, 11.11” MV(LD)
2141HC34 1.8L, 15.42” MV(LD)
2141HC35 1L, 13.36” FH(LD)
2141HC36 1.8L, 17.67” FH(LD)
2135HC15 1L, 14.15” FH(HD)
2135HC16 1.8L, 18.46” FH(HD)
Gas Entrainment Shaft Footless Magnetic Drive
2141HC29 1L,
9.45” MV(LD)
2141HC30 1.8L, 12.69” MV(LD)
2141HC31 1L, 11.70” FH(LD)
2141HC32 1.8L, 14.94” FH(LD)
2135HC43 1L, 12.47” FH(HD)(FMD)
2135HC44 1.8L, 15.72” FH(HD)(FMD)
Part No. Description Code
Impellers*
A358HC5 Impeller with set screws, 2” dia
358HC2F Set screws for A358HC5
& A2148HC3
A2138HC4 Impeller 2” HD(FMD)
A2148HC3 Impeller 2” LD(FMD)
709HCF Set screw for A2138HC4
2077HC Impeller, GE
Gaskets & Seals
48HC Gasket, silver; thermowell
48HCFG Gasket, gold plated
1808HCKL Head Gasket, Graphite
1808HCHA Head Gasket, PTFE
1498HCKL Gasket, bottom drain valve
2136HC Gasket, silver HD(FMD)
2136HCFG Gasket, gold plated HD(FMD)
2136HC2KL Gasket, Graphoil HD(FMD)
2142HC Gasket, silver LD(FMD)
2142HCFG Gasket, gold plated LD(FMD)
2142HC2KL Gasket, Graphoil LD(FMD)
