EN
1. Align and attach a simulated tank under the left wing using 1 screw.
Attach a tank under the other wing in the same way.
Tip: These scale features slow your aircraft much like the auxiliary tanks
on a full-scale Corsair.
NOTICE: NEVER ATTEMPT TO BELLy LAND your Corsair with only the belly
tanks installed or damage to the aircraft may result.
Installing Included Optional Belly Tanks
Optional Rough Runway Gear
Installing Decals
Intallation
1. The left and right optional gear (PKZ6007) are sold as a separate kit.
The coils on the forward-angled struts should face rearward. The wheels
project forward from the wing to decrease the possibility of tipping when
landing on a rough runway.
2. Install the left cover (
A) (marked L) on the optional left strut (B) using two
screws (
C).
3. Install the right gear using the right cover and 2 screws.
Removal
When needed, disassemble in reverse order.
3 X 10mm (2)
A
B
3 X 15mm (1)
3 X 15mm (4)
C
The included decals are for aircraft flown by the pilots Tommy
Blackburn “BIG HOG” and Ira Kepford. Only the left sides of these
aircraft are shown here. Apply decals in a similar pattern on the
right sides of the aircraft.
1. Ensure the fuselage is clean.
2. Lift a decal from a sheet and carefully apply it to the aircraft.
3. Rub out from the center of the self-adhesive decal to remove
bubbles.
