ParkZone PKZ1800 - Manual (Page 4)

6 7
In order to attach the wing of your P-51D Mustang,
please follow these simple instructions:
1. Locate the included wing screw (in clear plastic
bag).
2. Plug in the aileron servo leads from the wing into
the “Y” harness. Step 8 will guide you through the
process of ensuring the ailerons are correct and
not reversed.
3. Carefully attach the wing to the fuselage. The rear
of the wing plugs into the fuselage and the front of
the wing is secured with the wing screw.
1. Place the battery in the battery compartment and
secure in place with the hook and loop strap.
2. Plug the flight battery into the ESC with the blue
EC3 connectors. Do not plug balance lead of the
battery into the receiver; this will damage the
receiver and or battery.
1. Locate the horizontal stab of the tail.
2. Slide the horizontal tail stab through the allotted
space in the fuselage, making sure the control horn
attached to the horizontal tail stab will properly
align with the pushrod and clevis exiting the back
of the fuselage.
3. When you are certain the tail is centered correctly,
use the provided clear tape to properly secure the
tail to the fuselage, as shown. Use the tape on the
top and bottom of each side of the tail (total of 4
applications).
4. Make sure that the throttle slider is all the way
down, in the “off” position. Turn on the transmitter
and plug in the flight battery. Make sure the trim
levers and control stick are centered.
5. Locate where the clevis and rod exit the fuselage,
and attach the clevis to control surface as shown.
6. Make necessary trim adjustments prior to flight.
Top of Tail
Tape (4 pcs.)
Attaching the Wing Installing the Flight Battery
Attaching the Horizontal Stabilizer
