APPENDIX II – Valve, Spare Parts, Hardware and Cable Assembly Ordering Information
TBV Part Number and Ordering Information
Use the model number tree and matrix below to define a valid Nor-Cal Products throttling butterfly valve model number.
TBV
Drive Type
Nominal Port ID
Flange Type
Seal Material
Flange Size
Spare Parts
TABLE A-II.1 – TBV SPARE PARTS
MODEL
NUMBER
DESCRIPTION
54-310-004
Oldham Coupling Disk – Acetal. For all valves up to and including 4” (ISO-100)
54-330-006
Oldham Coupling Disk – Acetal. For 6” (ISO-160) valve and some UVD assemblies.
54-330-016
Oldham Coupling Disk – Acetal. For 8” (SIO-200) valve and some UVD assemblies
54-330-017
Oldham Coupling Disk – PEEK. For all valves up to and including 4” (ISO-100)
Call for details
Oldham Coupling Disk – PEEK. For 6” (ISO-160) valve and some UVD assemblies.
Call for details
Oldham Coupling Disk – PEEK. For 8” (SIO-200) valve and some UVD assemblies
TBV-400-90
Viton O-ring kit. Set of four. For all TBV sizes up to and including 4” (ISO-100)
TBV-600-90
Viton O-ring kit. Set of four. For 6” (ISO-160) TBV
TBV-800-90
Viton O-ring kit. Set of four. For 8” (ISO-200) TBV
TBV-1000-90
Viton O-ring kit. Set of four. For 10” (ISO-250) TBV
Cable Assemblies and Accessories
TABLE A-II.2 – TBV AND APC CABLE ASSEMBLIES AND ACCESSORIES
MODEL
NUMBER
DESCRIPTION
TBV-CRD-10
10’ (3 meter) APC controller-to-TBV valve cable
CDG-CRD-DB15-10
10’ (3 meter) APC controller-to-15-pin CDG cable
CDG-CRD-DB9-10
10’ (3 meter) APC controller-to-9-pin CDG cable
CDG-CRD-10
10’ (3 meter) APC controller-to-flying lead CDG cable
APC-CRD-RS232-10
10’ (3 meter) APC controller-to-host RS-232 interface cable. DB-9 connector on host end
APC-PSM-DB15
24 VDC, 3A power supply (100-240 VAC input) for IQ-series TBV. Includes AC power cord and 6’ (2 meter) DC cable with 15-pin D-sub connector
IQ-CRD-RS232-10
10’ (3 meter) long IQD-to-host RS-232 interface cable. DB-9 connector on host end
CDG-IQ-CRD-DB15-10
10’ (3 meter) long IQD-to-CDG interface cable. DB-15 connector on CDG end
CDG-IQ-CRD-Y
1’ (30 cm) long Y-cable used to interface two CDGs to IQD.
Call for details
RS-232 Service Software for Windows PC
DRIVE
TYPE
NOMINAL
PORT ID
FLANGE
TYPE
FLANGE
SIZE
SEAL
MATERIAL
D
= Direct drive
100
= 1
NW
= “KF” quick clamp style
25
= 1.00 NW
Blank
= Viton
G
= Geared drive
150
= 1
1
/
2
ISO
= ISO through bore
40
= 1.50 NW
Kxx*
= Kalrez
IQA
= IQ-Series with Analog/TTL and serial communications
*
200
= 2
CF
= Conflat metal seal
50
= 2.00 NW
Cxx*
= Chemraz
IQD
= IQ-Series with DeviceNet and serial communications
*
250
= 2
1
/
2
ASA
= ASA
63
= 2.50 ISO
Pxx*
= Perlast
*
Direct drive only
300
= 3
JIS
= JIS
80
= 3.00 ISO
xx*
= Other
400
= 4
100
= 4.00 ISO
*xx
Designates compound,
call for details
600
= 6
160
= 6.00 ISO
800
= 8
200
= 8.00 ISO
1000
= 10
250
= 10.00 ISO
