6
4x
7
2x
4
2x
1
Step 4
Insert the two Cable's Right Angle connectors items (4) through the holes
in the Dish,towords the Horn.Using 20mm open wrench ,connect the
Right Angle's Connectors to the Connectors on the Feed. Attach cable with
Cable Ties items (6) to strut nearby. Assemble Cable Grommets items (7)
on the cables (insertion from the dish concaved side)
and place them firmly in the Dish holes.
SHEET 3 OF 3
RD43078000C/B
