Connecting Accessories
32
Connecting Additional Devices
GTO Photo Beams
GTO Loop Detector
Mighty Mule
Push Button Control
According to
Application
According to
Application
Mighty Mule
Vehicle Sensor
Refer to Vehicle Sensor
manual for additional
connections.
Edge Sensor
ON
1
2
3
4
5
6
7
8
9
10
DIP
NO
COM
NC
V +
V –
LOOP
LOOP
LOOP
NOTE: Connections are for typical
applications. There may be additional
connection options for applications that
are not illustrated here.
