7.1
Figure 7.1:
Tonnage Monitor Module Installed in Card Rack.
Section 7
Installation
Section 7.1
Module Location
Figure 7.1 shows the OmniLink 5000 with the optional expansion rack and Tonnage Monitor Module
installed. The module must be securely screwed to the card rack with the knurled screws attached to the
faceplate of the card.
