April 17, 2000 Man ual Revisio n 1.0
5.2
Section 5.1.1 High Peak Alarm Stop
This parameter defines the type of stop signal sent to the press control when a High Alarm occurs in the
working portion of the stroke (View: Peak Tonnage). The following settings are allowed:
Setting=000 This programs the tonnage monitor module to send a Top Stop signal to the press
control.
Setting=001 This programs the tonnage monitor module to send a Cycle (immediate) Stop signal
to the press control.
Setting=002 This programs the tonnage monitor module to send an Hydraulic Overload signal to
the press control. This will cause the press control to Cycle Stop and turn OFF both
Output Relay 2 (OR 2) and Output Relay 3 (OR 3). This will take place only if the
press control has been configured by the factory to allow a hydraulic overload system
(see OmniLink 5000 press control manual). This feature provides benefit only if the
outputs (OR 2/3) control a mechanism that releases the hydraulic fluid in the overload
system quickly.
Section 5.1.2 High Data Window Alarm Stop
This parameter defines the type of stop signal sent to the press control when a High Alarm occurs in any
data window (View: Data Window 1-4). The following settings are allowed:
Setting=000 This programs the tonnage monitor module to send a Top Stop signal to the press
control.
Setting=001 This programs the tonnage monitor module to send a Cycle (immediate) Stop signal
to the press control.
Section 5.1.3 Number of Data Windows
This parameter defines the maximum number of data windows that the tonnage monitor module will
allow. In situations where less than four data windows will ever be used on a machine, this setting will
keep the CHANGE VIEW softkey from alternating through un-used windows. This does not affect the
number of data windows that can be turned OFF individually for a specific job.
The entry can be:
Setting=000 No Data Windows Allowed
Setting=001 1 Data Window
Setting=002 2 Data Windows
Setting=003 3 Data Windows
Setting=004 4 Data Windows
