80
Chapter 12 Part Number Reference
Table 16. Expansion Options or Spare Assemblies
Product ID
Description
SS7SPCI2SQ
SS7 Signaling Board, 4 SS7 links, 2 E1/T1, 2 V.11 ports
(use in conjunction with License Button)
SS7SPCI4Q
SS7 Signaling Board, 4 SS7 links, 4 E1/T1 ports
(use in conjunction with a License Button)
SS7HDPD4TEW
SS7 Signaling Board, 64 SS7 links, 4 E1/T1 ports
(use in conjunction with a License Button)
SS7SBPCISYSQ
License Button (Install in SS7SPCI2SQ and SS7SPCI4Q Signaling Boards above)
SS7SBHDFBGQ
License Button (Install in the SS7HDPD4TEW Signaling Board above)
SS7G20SACPSU
AC Power Supply Module [TLPACPSU002]
SS7G20SDCPSU
DC Power Supply Module [TLPDCPSU002]
SS7G20SHDD
Spare Hard Drive with software for SS7G2x
Table 17. Accessories
Product ID
Description
SS7G20R19LBR
2-post 19” rack mount ‘L’ bracket kit. See
Section 5.4, “Rack Mounting Options”
for more information. [TMLCMOUNT21]
SS7G20R19MNT
2/4-post 19" rack mount, See
Section 5.4, “Rack Mounting Options” on page 34
for more information. [TMLPMOUNT51]
SS7G20R23MNT
2/4-post 23" rack mount. See
Section 5.4, “Rack Mounting Options” on page 34
for more information. [TMLPMOUNT52]
SS7G20RSLKIT
Enabling kit for use with slide rails. See
Section 5.4, “Rack Mounting Options” on
for more information. [TMLPSLIDE01]
SS7DKL26
Splitter Cable Assembly, SS7 Serial Interface Port, 2 metres long,
(26-way dual V.11) splits to 2 x (DB15 - V.11). See
Table 7, “SS7 Serial Interface
Port Splitter Cable 15-Way Male DB15 Connector Pinouts” on page 38
CBLCTB3DROPQ
Ribbon Cable, H.100, 3 drop - Joins H.100 connectors of SS7 Signaling Boards
