Chapter 6: Maintaining The Procedure Station
Product Service 1-800-522-7658 43
Original instructions
Font Panel Removal and Installation:
1. Locate and remove the two Phillips
screws that secure the front panel as
shown in Figure 6-3. They are
located on the bottom corners of the
front dress panel.
2. Swing the bottom of the dress panel
out to clear the fluorescent light and
then lift the front dress panel
straight up and away from the
cabinet.
1. To reinstall the panel, reverse these
steps, ensuring that the plastic pin
in the top corners of the dress panel
properly engage the corner posts.
Figure 6-4
Figure 6-3
