Appendix A: Filtered Enclosure Components and Replacement Parts
Product Service 1-800-522-7658 61
Item Qty. Part Number Description
1 1 3911000 Glass, Side
2A 1 3911900 Glass, Sash 2'
2B 1 3911901 Glass, Sash 3'
2C 1 3911902 Glass, Sash 4'
3A 1 3991500 Sash Assembly, 2'
3B 1 3991501 Sash Assembly, 3'
3C 1 3991502 Sash Assembly, 4'
4A 1 3905600 Lower Air Foil, 2'
4B 1 3905601 Lower Air Foil, 3'
4C 1 3905602 Lower Air Foil, 4'
5A 1 3907400 Bracket, Air Foil R.H.
5B 1 3907401 Bracket, Air Foil L.H.
6A 1 3907500 Stop, Sash R.H.
6B 1 3907501 Stop, Sash L.H.
7A 1 6916500 Latch, Sash
7B 1 3906700 Bracket, Latch
7C 1 1927403 Spring, Compression Latch
7D 2 1893206 Screw, 8-32 x .38" Lg. Phillips Pan S.S. Type F
9A 2 1889316 Screw, 10-24 x 1.00 PH Phil S.S.
9B 2 1912108 Washer, Plastic .194 ID. x .380 OD
9C 2 7868402 Bushing, Spacer .31 x .63
10 1.9 Ft 6913700 Wiper, Sash Seal
11A 2 1936800 Bushing, Heyco closed 1.50 Dia.
11B 2 1934601 Bushing, Heyco w/ Flex Shutter 1.50 Dia.
12A 1 3915401 Side Air Foil
12B 2 1889912 Screw, #6-32 x .75" Oval Hd. Type F (S.S.)
13A 1 3907700 Reflector, Light 2'
13B 1 3907701 Reflector, Light 3'
13C 1 3907702 Reflector, Light 4'
13D 2 1889308 Screw, Mach. 10-24 x .50 PH Phillips
14A 1 3708300 Lamp, Fluorescent 2' Enclosure (F15T8-SP35)
14B 1 9721902 Lamp, Fluorescent 3' Enclosure (F17T8)
14C 1 9721901 Lamp, Fluorescent 4' Enclosure (F25T8)
15A 1 1270100 Lamp, UV 2' or 3' Enclosure (G15T8)
15B 1 1271300 Lamp, UV 4' enclosure (G30T8)
16A 1 3911700 Bracket, Right Reflector Support
16B 1 3911701 Bracket, Left Reflector Support
16C 4 1893108 Screw, #8 x 1/2 AB Hex Washer Head
