Chapter 7: Accessorizing Your Enclosure
Product Service 1-800-522-7658 31
Dimensions of 7068200 and 7068300 Blowers
7.
Exhaust Dampers
Exhaust dampers allow adjustments to maintain proper airflow for roof-
mounted blowers or house exhaust systems and can be located anywhere in the
exhaust.
Catalog # Description
3924000 6" Epoxy Coated Steel In-Line adjustable damper
4724200 6" PVC In-line adjustable damper
4741300 8" PVC In-line adjustable damper
5983400 10" PVC In-line adjustable damper
Dimension Models 70682003 and 7068300
A 7.16"
B 7.00"
C 8.13"
D 6.81"
E 9.25"
Inlet 10.87 ID
Outlet 5.5" x 10.00" W
Wheel 9.19" x 4.25" W
