Chapter 3: Getting Started
Product Service 1-800-522-7658 13
XPert Enclosure
The exhaust connection on the enclosure has been designed to accept a 2" x 10"
(5.1cm x 25.4cm) nominal transition adapter. See Chapter 7 for ordering
accessory transition adapters. Labconco manufactures transition adapters for top
exhaust. Labconco recommends that the 6" dia. Transition Adapter(3912401) be
used for house exhaust on all 5', 6' and 8' XPert Bulk Powder Enclosures.
Labconco recommends balancing the airflow when using multiple FilterMate
Portable Exhausters. For the 8' XPert Bulk Enclosures, Labconco recommends
using the 6x6x8 exhaust transition tee for exhausting to the outside. Review
Chapter 2 for exhaust prerequisites and review Chapter 7 for ordering blower
exhaust equipment. For your convenience several exhaust options are shown in
Figures 3-2 and 3-3. Consult Labconco Customer Service should you require help
sizing your blower for the exhaust volume and system static pressure loss.
Figure 3-3
XPert Bulk Enclosure connected to two FilterMate Portable Exhausters
3912400, 5" Transition Adapters
