Chapter 6: Maintaining Your Enclosure
Product Service 1-800-522-7658 26
Programming the Guardian 1000 Digital Alarm
Set the desired face velocity of the enclosure with the sash in the down position
using an average face velocity of readings from a thermal anemometer.
a.
2 ft enclosure – 2 readings
b.
3 ft enclosure – 3 readings
c.
4 ft enclosure – 4 readings
Configure Alarm
To successfully calibrate the airflow monitor, it will be necessary to change the
face velocity by adjusting the airflow exhaust volume. The exhaust volume can be
adjusted using the speed control located behind the front panel on the XPert
Filtered System or on the back of the FilterMate. For the XPert Filtered Station,
the exhaust volume is adjusted through a damper in the building exhaust system.
The following inflow face velocity speeds are recommended to successfully
calibrate. To begin, determine what the low airflow, low warning airflow, normal
airflow, and high airflow shall be.
Low Air Alarm
Set Point
(user defined)
Enclosure
Operating
Inflow Speed
Low Calibration
Set Point
(user defined)
High Calibration
Set Point
(user defined)
40 – 50 fpm 60 fpm 40 – 60 fpm 100 – 120 fpm
60 – 70 fpm 80 fpm 50 – 90 fpm 100 – 150 fpm
80 - 90 fpm 100 fpm 50 – 110 fpm 100 – 170 fpm
NOTE: ENTER button stores information
+/- Buttons allow for scrolling.
1.
Push the ENTER button on the face of the alarm until the Set-Up Menu is
displayed.
2.
Scroll to SET UP and hit ENTER.
3.
The PASSWORD MENU displays (The Password is 0000). Press the
ENTER button repeatedly until the CAL CONFIG MENU is displayed.
4.
In the CAL CONFIG MENU set for the following:
