15. Appendices
30
IPD SERIES Operation Manual rev 1.0.0
15.3. Technical specifications
Model - IPD 2400
General
Number of channels (not bridgable)
2
Maximum total output power 2400 W
Output voltage 100 V peak / 70 Vrms / 39.2 dBu
Output current 20 Arms
Max. Output Power (all ch.’s driven)
2 ohms
800 W
4 ohms 1200 W
8 ohms 600 W
16 ohms 300 W
Performance
THD+N 20 Hz - 20 kHz @ 1 W
<0.1%
THD+N @ 1 kHz, 1 dB below clip <0.05%
Output noise -66 dBu
Signal To Noise Ratio 105 dB
Channel separation @ 1 kHz >80 dB
Frequency response (-3 dB) 2 Hz - 42 kHz
Input impedance 18 kOhm
Common Mode Rejection (CMR) >50 dB
Output impedance 25 mOhm
Input sensitivity for maximum output voltage 6 dBu
Maximum analog input level 20 dBu
Gain (all DSP controls set to 0 dB) 33.2 dB
Mains power
Nominal mains voltage
100 - 240 VAC
Operating mains voltage 60 - 265 VAC
Standby consumption <7.5 W
Mains connector Locking IEC inlet
Physical
Dimensions (Rack rail - rear panel)
W: 483 mm (19”), H: 44 mm (1 U), D: 359 mm (14.1”)
Dimensions (over all incl. handles & rear support) W: 483 mm (19”), H: 44 mm (1 U), D: 431 mm (17.0”)
Weight 6.2 kg (13.7 lbs)
Finish Black, anodized aluminium front panel. Black/grey steel chassis
Connectors
Analog input connectors per channel
3-pin XLR female
Analog input link connectors per channel 3-pin XLR male
AES input connector 3-pin XLR female
AES input link connector 3-pin XLR male
Output connectors per channel Neutrik speakON / Binding posts, electronically balanced
Network connector RJ45 (Ethernet)
Buttons
Power
Menu
Back
Mute (per channel)
Power
Encoder
Adjust/Set
LED’s
Signal / Mute (per channel)
Limit (per channel)
Power State
Approvals CE, UL (ANSI/UL, CAN/CSA), PSE, RCM, CCC, FCC.
All specifications are subject to change without notice.
