LA Audio MPX10 User Manual
Page 3
Page 3
CONTENTS
Page
1 .
Introduction
3
2 .
Installation
4
2.1
Inspection and un-packing
4
2.2
Operating environment
4
2.3
CE standards
4
2.4
Power requirements
4
2.5
Signal levels
5
2.6
External connections
6
3 .
Warranty
9
4 .
Description of controls
10-15
4.1
Input section
10
4.2
Noise Reduction and Compressor section
11
4.3
Equaliser section
13
4.4
Output section
5 .
Applications
16-21
5.1
Input
16
5.2
Compressor
16
5.3
Expander
18
5.4
Equaliser
18
5.5
Output
20
6 .
Circuit description
21
6.1
Inputs
22
6.2
Expander and Compressor
22
6.3
Output
23
7 .
Specifications
24
