3
Dimensions: 122x122x26 mm
Weight: 395 g
Safety precautions:
• Do not open the camera or receiver in the event of a malfunction. These products should only be
opened by a qualified engineer.
• Do not submerge the camera in liquid.
• Do not expose the receiver to water or humidity.
• Do not expose the receiver or camera to high temperatures (see technical specifications)
• Do not install the system close to strong magnetic fields, such as a speaker. This may affect the
quality.
Product description:
Remote control Receiver
Monitor Menu Playback REC mode Other
1 LINK indicator
2
POWER
indicator
3 Switch CHANNEL Cursor UP Fast FORWARD
4 Volume DOWN Cursor LEFT
Volume DOWN / Switch
display CHANNEL
5 Volume UP
Cursor
RIGHT
Volume UP / Switch display
CHANNEL
6 MENU OK / ENTER PLAY / PAUSE
7 Switch CHANNEL
Cursor
DOWN
Fast BACKWARD
8 ESCAPE EXIT PREVIOUS
9
RECORDING /
STOP
DELETE STOP
10 ZOOM NEXT
11 ALARM
12 POWER on/off
