8
ENGLISH
Sliding mouse: Slide the mouse to select a motion area if you are in motion
mode. Slide the mouse to adjust colour and volume if you
are in colour settings menu mode.
Installation instructions
To camera input
To DC 12 V input
Connect divider cable to power supply
Max. 4/8/16 camera
inputs
To AC 220 V power outlet
Connection cable
AC/DC power
supply
Divider cable
with 5x DC
output
User instructions
The following chapters describe some of the features and functions of the DVR. Refer to
the extensive English manual for further details about the DVR. For system settings, it is
recommended to use the mouse.
Note: the system language can be set to several languages. The screenshots in this manual,
however, are shown only in English.
