5
ENGLISH
• Video output: 1.0 V p-p/75 Ω
• Voltage: DC 12 V
• Dimensions: 145 x 60 x 55 mm
• Weight (with bracket): 350 g
Camera SAS-CAM1200/1210
• Image chip:
1/4" CMoS
• lens: 3.6 mm
• horizontal resolution: 700 TVl
• View angle:
• Infrared lED:
• light sensitivity:
• Electronic shutter:
• S/N ratio:
• Gain:
• Gamma correction:
• Protection:
45°
24 pcs, 5 ~ 10 m
1.5 lux
1/50 (1/60) ~ 1/100.000 sec.
> 48 dB
auto
> 0.45
IP66
• Working temperature: -20 °C ~ 55 °C
• Video out: 1.0 V p-p/75 Ω
• Voltage: DC 12 V
• Dimensions: 100 x 75 mm
• Weight (with bracket): 250 g
Safety precautions
Do not open the camera or DVR in the event of a malfunction. These products should only be
opened by a qualified engineer.
Do not submerge the camera and DVR in liquid.
Do not expose the DVR to water or humidity.
Do not expose the camera or DVR to high temperatures (see technical specifications).
Do not install the system close to strong magnetic fields, such as speakers. This may affect the
performance of the system.
Product description
Front panel (SAS-DVR1004 shown)
