- Speed : .11(4.8V) /.10sec(6.0V)
- Torque : 2.6(kg/cm) / 36oz at 4.8V
3.0(kg/cm) / 41oz at 6.0V
- Size : 30 x 12 x 30(mm) / 1.2 x 0.47 x 1.2(inch)
- Weight : .58oz/16.6g
3
3 System Components
Receiver
Currently there are two popular receivers used in the Neon 3 packages.
Deluxe Version includes : Electron 6 channel Dual Conversion 6 channel FM receiver
Micro version includes : HFS-04MG 4 channel Single Conversion 4 channel FM receiver
Servo
Currently there are two popular servos choices offered in the Neon 3 packages.
Deluxe Version includes : (2) HS-81 micro servos
Micro version includes :(2) HS-55 sub-micro servos
Accessories
One CG-25 or CG-22A overnight wall charger, part # 43025 or # 43022
One Switch harness, part # 54403
One AAA receiver battery box, part # 54402
4 Set-up and Operation
Transmitter
Opening the case
The case of your Neon is unique because it does not have
the traditional screws holding it together.
Instead, we have created a "pull apart" case to facilitate
access to the inside components.
To open your case, unscrew the antenna and remove it,
slide the tabs located at the bottom corners off and gently pull
the bezel at the base of the antenna up, and then remove the
crystal (See Image). Now, separate the two case half's while
being careful of the internal wiring harness to the throttle switch,
unplug the wires leading to the throttle switch, and you can
now access the internal components to add optional feature
packages, reverse your servos, or change the battery out.
- Size: 45.5 x 22.5 x 15.0 (mm) / 1.79 x 0.88 x 0.59 (inch)
- Weight : 17g(0.6oz) without X-tal
- Size: 25 x 37.5 x 16 (mm) / 0.98 x 1.47 x 0.62 (inch)
- Weight : 15.9g (.55oz)
- Speed : .17(4.8V) /.14sec(6.0V)
- Torque : 1.1(kg/cm) / 15oz at 4.8V
1.3(kg/cm) /18oz at 6.0V
- Size : 23 x 12 x 24(mm) / 0.90 x 0.45 x 0.94(inch)
- Weight : .28oz/8.0g
OPEN OPEN
