2
1 Introduction
Congratulations, you now own one of the most unique and revolutionary radio control systems in the world.
The Neon 3 was created for the beginner and seasoned R/C enthusiast to grow with your needs and skill level.
The basic Neon can be upgraded with a variety of features like;
- A 4th channel three position switch
- Dual Rates on channels 1 and 2
- ATV's on channel 1, 2 and 3 - A trainer port and switch package
Any way you choose to customize your Neon, you are sure to be satisfied with the performance on this unique system.
Table of contents
Page 2
Page 3
Page 4
Page 5
Page 6
Page 7
Page 8
1. Introduction
2. Features and Specifications
Transmitter
Options
3. System Components
Receiver
Servo (Standard version, Micro version)
Accessories, all systems
4. Set-up and Operation
Transmitter
Reading the LED Battery Indicators
Recharging Nicad batteries
Installing Transmitter Batteries
To install or change the batteries in your NEON
Transmitter antenna
Elevon/V-tail mix
Servo Reversing
Gimbal stick length adjustment
Gimble stick tension adjustment
Throttle Function
5. Installation of Receiver and Servos
Turning on your system
Servo trim settings
Range check
Checking servo operation
6. NEON Transmitter Option Installation Directions
Trainer Port and Switch Installation
ATV Board Installation
Dual Rate Switch Installation
4th Channel Three Position Switch Accessory Installation
Transmitter
- Single Stick 3 channel, (upgradeable to
4 channel) FM proportional system
- Dual axis precision gimbal
- Adjustable gimbal stick length
- Adjustable gimbal stick tension
- 3 LED battery status indicators
- Charging jack for optional internal Nicad battery
- Servo reversing for all channels
- Elevon or V-tail mixing function
- Proportional 3rd. channel slide switch
- Channel 1 and 2 trim levers
Options
- Channel 4 three position switch, part # 54301
- Channel 1,2 and 3 ATV function, part # 54302
- Trainer plug and switch, part # 54303
- Channel 1 and 2 Dual Rate function part # 54304
(Must use optional part# 54304, ATV function in
addition to this option)
2 Features and Specifications
