Lithium
Additional Features & Settings
When the charge process starts, the integrated safety timer starts to run simul-
taneously. If an error occurs or the termination circuit cannot detect whether
the battery is fully charged or not, the X1 is programmed to prevent overcharg-
ing and will terminate the charging process.
Safety Timer Calculation
When charging NiCd or NiMH batteries, divide the capacity by the current,
then divide the result by 11.9. Set this number of minutes as the setting for the
safety timer setting. If the charger stops at this time threshold, about 140% of
the capacity will have been fed into the battery.
See pg. 28 for instructions on accessing the “
Safety Timer
“ screen.
Press the
► button once and “
ON
” will begin fl ash-
ing. Use the ✚ or ▬ buttons to turn the timer off . We
strongly recommend that you leave the Safety Timer on.
Press
► to set the Safety Timer.
Safety Timer
Safety Timer
ON 120min
This program provides a maximum capacity protection function. If the Delta-
peak voltage can not be detected or the Safety Timer times out, the charge pro-
cess will stop automatically when the battery reaches the user-set maximum
charge capacity in order to prevent accidental overcharging.
See pg. 28 for instructions on accessing the “
NiCd Sensitvity
“ screen.
Press the
► button once and “
ON
” will begin fl ashing.
Use the ✚ or ▬ buttons to turn the Safety Timer off .
Press the
► button again and the mAH value will begin fl ashing. Use the ✚
or ▬ buttons to change the mAHvalue. This can be set between 10mAH and
50,000mAH.
Press
► to save these settings.
Capacity Cut-off
Capacity Cut-off
ON 5000mAH
