HITEC X1 AC Plus: Single Port AC/DC Chargers User Manual
Page 22

22
BEFORE YOU BEGIN DISCHARGING YOUR BATTERY, MAKE SURE YOU
HAVE READ AND UNDERSTAND ALL OF THE WARNINGS AND SEFETY
INFORMATION CONTAINED ON PAGES 4-7.
After selecting the correct battery type (see pg 21), use the ✚ or ▬ buttons to
select to the “
DISCHARGE
“ mode.
Press the
► button and the amp rate value will begin
fl ashing. Use the ✚ or ▬ buttons to adjust the value
to the desired rate. Follow the instructions provided with your battery when
setting the amp rate.
Press the
► button again and the voltage cutoff will
begin to fl ash. Use the ✚ or ▬ buttons to adjust the
value to the desired rate. Follow the instructions provided with your battery
when setting the voltage cutoff . The X1 will stop discharging when the battery
has reached the preset voltage cutoff .
Press and hold the
► button to begin discharging.
Once discharging has commenced, the charger will
display the following real-time information: Battery type, discharging current,
battery voltage, discharging time and discharged capactiy.
When discharging is complete the X1 will chime.
Press and hold the
► button to begin charging.
Once charging has commenced, the charger will dis-
play the following real-time information: Battery type,
charging current, battery voltage, charging time and charged capactiy.
Once the battery is fully charged the screen will read “
FULL
” and the charger
will emit a chiming sound. Press the ■ button to stop charging. You may press
the ■ button at any time during the charging process to stop charging.
NiCd/NiMH
Charge Mode (cont.)
NiCd/NiMH
Discharge Mode
Lithium
NiCd/NiMH
NiMH 1.4A 5.98V
CHG 022:43 00384
NiMH 1.4A 5.98V
CHG 022:43 00384
NiMH DISCHARGE
0.1A 0.1V
NiMH DISCHARGE
0.1A 0.1V
Warning
