HITEC X4 AC Plus: Four Port ACDC Multi-Charger User Manual

Page 5

• A battery pack which consists of different types of cells

(including different manufacturers)

• A battery that is already fully charged or just slightly discharged

• Non-rechargeable batteries (they pose an explosion hazard)

• Batteries that require a different charge technique from NiCd, NiMH, LiPo

or gel cell (Pb, lead-acid battery)

• A faulty or damaged battery

• A battery fitted with an integral charge circuit or a protection circuit

• Batteries installed in a device or which are electrically linked to other

components

• Batteries that are not expressly stated by the manufacturer to be suitable for

the currents the charger delivers during the charge process

• Did you select the appropriate program suitable for the type of battery you are charging?

• Did you set up adequate current for charging or discharging?

• Have you checked the battery voltage? Lithium battery packs can be wired in parallel

and in series, i.e. a 2-cell pack can be 3.7V (in parallel) or 7.4V (in series).

• Have you checked that all connections are firm and secure? Make sure there are no

intermittent contacts at any point in the circuit.

Before you Start Charging or Discharging your Batteries Consider the

Following

Never Attempt to Charge or Discharge the Following Types of

Batteries

3.7V/cell

Nominal

Voltage

Min. Discharge

Voltage

Max Charge

Voltage
Storage

Voltage
Allowable

Fast Charge

3.7V/cell

4.2V/cell

3.8V/cell

≦

≧

3.0V/cell

LiPo

LiIon

3.6V/cell

4.1V/cell

≧

2.5V/cell

≦

3.3V/cell

3.6V/cell

3.3V/cell

≦

≧

2.0V/cell

LiFe

1.2V/cell

1.5V/cell

n/a

1C-2C

≧

0.85V/cell

NiCd

1.2V/cell

1.5V/cell

n/a

1C-2C

≧

1.0V/cell

MiMH

2.0V/cell

2.46V/cell

n/a

≦

0.4C

≧

1.75V/cell

WARNING

FAILURE TO FOLLOW THESE IMPORTANT SAFETY NOTES OR THE INSTRUCTION

MANUAL CAN RESULT IN SEVERE INJURY, PROPERTY DAMAGE OR LOSS OF LIFE.

Please read this entire instruction manual completely and attentively before using

this product, as it covers a wide range of information on operation and safety.

Never leave the charger unattended when it is connected to its power supply. If any

malfunction is found, TERMINATE THE PROCESS AT ONCE and refer to the

instruction manual.
Keep the charger away from dust, moisture, water, excessive heat, direct sunlight

and vibration.

The maximum allowable input voltage is 120 VAC when using the supplied AC power

cord or 15V DC when using an external DC power source.

The charger and the battery should be put on a heat-resistant, non-flammable and

non-conductive surface. Never place them on a car seat, carpet or other flammable

surface. Keep all flammable volatile materials away from the operating area.

Make sure you know the specifications of the battery you are charging or discharging

to ensure it meets the requirements of this charger. If the program is set up incor-

rectly, the battery and charger may be damaged. Fire or explosion can occur due to

overcharging.

To avoid short circuiting between the charge lead, always connect the charge

cable to the charger first, then connect the battery. Reverse the sequence when

disconnecting.

Charging

During the charge process, a specific quantity of electrical energy is fed into the battery.

The charge quantity is calculated by multiplying charge current by charge time. The

maximum permissible charge current varies depending on the battery type or its perfor-

mance, and can be found in the information provided by the battery manufacturer. Only

batteries that are expressly stated to be capable of quick charge should be charged at

rates higher than the standard charge current.
Connect the battery to the terminal of the charger. Red is positive and black is negative.

In the event there is any significant resistance in the battery cable and/or connector, the

charger will not be able to properly detect the resistance of the battery pack resulting in

an error. It is essential in order for the charger to operate properly that the battery charge

leads should be of adequate quality for the size of the battery.
Always refer to the manual by the battery manufacturer pertaining to charging methods.

Operate according to their recommended charging current and charging time. Lithium

batteries, in particular, should be charged strictly according to the manufacturer's

instruction.
Pay close attention to the connection of lithium batteries.
Do not attempt to disassemble the battery pack.
Please take note that lithium battery packs can be wired in parallel and in series. In the

parallel connection, the battery’s capacity is calculated by multiplying the single battery’s

capacity by the number of cells, bearing in mind that total voltage stays the same. If the

voltage is imbalanced, it may cause a fire or explosion. Lithium batteries are always

recommended to be charge in series.

WARNINGS AND SAFETY INFORMATION

Standard Battery Parameters
