ASSEMBLY INSTRUCTIONS - P51D MUSTANG (cont.)
STEP 6 STEP 7
Fuselage
59011
Main Wing
59012
Horizontal Stabilizer
59013
Vertical Stabilizer
59014
Landing Gear
59015
Canopy
59016
Spinner
59017
Propeller
59018
Controlling Linkages
59036
WBL-1200 Brushless Motor
59040
*WS9 9g Servo - 150mm Lead (tail)
**WS9 9g Servo - 300mm Lead (wing)
59037 * 59038 **
WBE-12A Brushless ESC
59039
SPARE PARTS - P51D MUSTANG
Step 6: Installing the Receiver and Battery
Install the receiver into the fuselage and plug
in the servo leads. Install the battery into the
cavity in the front section of the fuselage as
shown above.
Step 7: Check the Center of Gravity (CG)
Check the Center of Gravity on your model
by balancing it on your fi ngers. The CG
should be about 2 1/2 ~ 2 7/8 th inches
(65 ~ 72 mm) behind the leading edge of
the main wing as shown in the diagram.
You can adjust the CG by moving the bat-
tery forward or backwards.
