EYE-C-GAS user's manual
Page 33 P/N PS8G9006-Rev 1
www.heathus.com www.opgal.com
7 Connectivity to other Devices
The EYE-C-GAS camera, when connected to a PC using USB2, will appear to the PC as a flash
drive. Experienced PC users will be able to explore the contents of the SD memory card which
will contain the original compressed H264 video files, the WAV audio files and camera files. In
the event Artsoft is not available and free space must be made available on the SD memory card,
the H264, WAV and camera files can be downloaded to a PC and then deleted from the camera.
A third party conversion program will then be required to merge and convert the original files to
MP4 and / or WMV. The original files can also be uploaded back into the SD memory card at a
later date and Artsoft then used.
The accessories connector (see Figure 1) can also be used with the optional BNC Video Adapter
for real-time viewing of the infrared image on an external device such as a projector or monitor.
Playback is not supported in the analog video output. The analog infrared video output is in
composite form. A BNC to RCA adapter can be used along with a cable with the video adapter
for easy connection to the “yellow” RCA input on the external device. The analog video output
must be enabled (set to ON) in the Menu. See Section 5.1.5.9 for details. When not needed, the
analog video output should be disabled (set to OFF) to conserve power.
