71 User Controls
OSD Menu Functions
IND100064-38
|---2---
Management Settings - Communication *Available in “Full Mode” only
The unit allows for remote control (adjust brightness for example) and/or accessing internal
information about the unit such as typenumber, serial number and more. To setup this feature, you
first need to configure the Serial or Ethernet protocol properly to match your external equipment
specifications. The contents of the submenus is listed below.
Settings as follows:
“RS232” = Sets the internal communication to standard RS-232 protocol.
“2-wire RS-485” = Sets the internal communication to RS-485 protocol
(Half duplex).
“4-wire RS485/422” = Sets the internal communication to RS-485/422 protocol
(Full duplex).
“Address RS” = Set the global unique channel/port ID for the unit, 16 ID’s available.
“IP Address” = IP can be found Automatically or you can set the IP address
manually (xxx.xxx.xxx.xxx) for Ethernet protocol by choosing
“Fixed IP”.
“Download” = Allows Factory Firmware upgrade for the unit via RS-232 Serial
Communication.
● Note: Default mode is “RS232” protocol.
A more detailed description of the SCOM (Serial/Ethernet Communication) can be found here:
http://www.hatteland-display.com/pdflink/inb100018-4.php
Review also the “Pinout Assignments” chapter in this manual for additional help during preperation
and/or installation of external equipment intended to communicate with.
