35 34
SMS DELIVERY
HI504901 is able to send SMSs to one (or two) cellular
phone number(s). HI504901 can send two types of mes-
sage: alarm SMSs (upon an alarm condition at least in one
of the instruments connected to the interface) and informa-
tion SMS (upon specific request from the user).
Note To use the SMS feature, a SIM card able to make a voice call
must be used.
ALARM SMSs
Alarm messages are submitted by HI504901 to the cellular
phone number(s) when an error occurred on one of the instru-
ments connected to the interface. A message about an alarm
condition in one instrument will be sent by the interface only if
the alarm is active and the specific alarm notification was en-
abled during last configuration, by checking the proper box on
the “message option” window of the selected device (see “Inter-
face configuration” section). If an alarm is active in one
instrument connected to the interface but its notification was not
enabled during last configuration, then no SMS will be sent
(however HI504901 gives indication to the user about the
error condition by turning on the red LED for the RS232 chan-
nel or RS485 port or digital input port where the instrument is
connected).
Note An alarm SMS can be sent only if SMS sending is user en-
abled through digital input terminal (#8 on page 8), other-
wise no SMS will be issued.
The format of alarm messages for instruments connected to the
RS232 ports will be:
“; RS232-CHANNEL>; Alarms: MENT>; Rem msg: MESSAGES>”
The format of alarm messages for instruments connected to the
RS485 port will be:
“; RS485-DRESS>; Alarms: ;
Rem msg: ”
During alarm condition, the field INSTRUMENT> on the alarm message will contain the list of
Item Default value
Telephone #1 empty field
Telephone #2 empty field
Date from internal RTC
Time from internal RTC
Remaining SMSs disabled
Expiration date disabled
Repeated SMSs 2
SMS delay 10 minutes
Query delay 1 minute
Password disabled
PIN empty field
RS232 options no instrument configured
RS485 options no instrument configured
Digital input disabled
Digital output disabled
open the digital output contact. If the digital output control is
enabled, when an information will be requested to HI504901,
an SMS with the digital output status will be sent.
Note By disabling this option, it will not be possible to set the digi-
tal output status and no information SMS about the digital
output will be sent.
Note If the digital output management is disabled, the digital output
will be automatically opened, even if it was previously closed.
Note If the password is not set, only “CLOSEP” or “OPENP” SMS
must be sent.
Default values
The following table lists the default value for previous items,
i.e. the factory values copy from ROM if HI504901 was
never configured.
