Hanna Instruments HI 98401 User Manual

Page 3

HI 98401 measures fluoride from 0.05 mg/L to 1.9 g/L in 5 distinct
scales. With auto-ranging HI 98401 automatically selects the range
that provides the best resolution. All results are displayed directly in
fluoride concentration. In order to guarantee maximum repeatability,
measurements are performed using the FC 301B fluoride specific
electrode and the separate HI 5313 reference electrode.

HI 98401 compensates for temperature automatically from 5 to 35°C
using the optional HI 7662 stainless steel temperature probe. The
temperature measured together with fluoride concentrations are dis-
played on the large LCD simultaneously.

All operations are microprocessor controlled for added precision and
simplicity. The calibration is automatic at one or two points. The first
calibration point is in the middle of the range at 100 mg/L (ppm). The
slope can then be selected for low fluoride measurements at 10 mg/L,
or higher contents at 1000 mg/L.

HI 98401 is supplied in a rugged carrying casing complete with 4
batteries, that provide up to 120 hours of continuous operation.

GENERAL DESCRIPTION

ACCESSORIES

Calibration Solutions
HI 7023/1L

TISAB fluoride solution,1 L bottle

HI 7023L

TISAB fluoride solution, 500 mL bottle

HI 70701/1L 1 g/L fluoride solution, 1 L bottle
HI 70701L

1 g/L fluoride solution, 500 mL bottle

HI 70701M

1 g/L fluoride solution, 230 mL bottle

HI 70702/1L 10.0 mg/L fluoride solution, 1 L bottle
HI 70702L

10.0 mg/L fluoride solution, 500 mL bottle

HI 70702M

10.0 mg/L fluoride solution, 230 mL bottle

HI 70703/1L 100 mg/L fluoride solution, 1 L bottle
HI 70703L

100 mg/L fluoride solution, 500 mL bottle

HI 70703M

100 mg/L fluoride solution, 230 mL bottle

Maintenance Solutions
HI 7061M

General purpose cleaning solution, 230 mL bottle

HI 8061M

General cleaning solution, 230 mL FDA bottle

HI 7061L

General cleaning solution, 500 mL bottle

HI 8061L

General cleaning solution, 500 mL FDA bottle

HI 7073M

Protein cleaning solution, 230 mL bottle

HI 8073M

Protein cleaning solution, 230 mL FDA bottle

HI 7073L

Protein cleaning solution, 500 mL bottle

HI 8073L

Protein cleaning solution, 500 mL FDA bottle

HI 7077M

Oil and fat cleaning solution, 230 mL bottle

HI 8077M

Oil & fat cleaning solution, 230 mL FDA bottle

HI 7077L

Oil and fat cleaning solution, 500 mL bottle

HI 8077L

Oil & fat cleaning solution, 500 mL FDA bottle

HI 7082

3.5M KCl electrolyte solution, 4 x 50 mL bottle

HI 8082

3.5M KCl electrolyte solution, 4 x 50 mL FDA bottle

Other Accessories
FC 301B

Fluoride electrode with BNC and 1 m (3.3') cable

HI 5313

Reference electrode with 1 m (3.3') cable

HI 7662

Temperature probe with 1 m (3.3') cable

HI 76405

Electrode holder

PRELIMINARY EXAMINATION

Remove the instrument from the packing material and examine it
carefully to make sure that no damage has occurred during shipping.
If there is any noticeable damage, immediately notify your dealer.
Each meter is supplied complete with:

• Batteries (4 x 1.5V AA)
• Instruction manual
• Rugged carrying case

Note: Save all packing materials until you are sure that the instru-

ment functions correctly. Any damaged or defective item must
be returned in its original packing materials together with the
supplied accessories.
