A / V Switch-Cat

TM

7

Prior to final installation of the user interface and connector panel wall
plates, you need to use the supplied Windows™ software and the serial
cable to program the serial codes needed to operate the projector into the
sender wall plate.

Note on CV and S-Video Inputs

Do not connect the Composite Video and S-Video inputs
simultaneously. Doing so will produce a poor quality image

Note on RS-232 port availability on your PC

Most PCs and notebooks do not have a serial port. So to
program the sender you may need a USB to RS-232 Serial
converter. These are available from Hall Research (Model USB-
RS232-1).

For more on the topic of Serial Control of the projector please refer to
Section 5.0
