Model VSA-31-SP
14
. Loading or Saving Configurations
You can save or load a configuration file by clicking on the File menu or
choosing the appropriate icon. You can also create a new configuration
file from the File menu or the New File icon
. Uploading to the VSA-31-SP
To upload to the VSA-31-SP, make sure the VSA-31-SP is connected to
the PC, via the supplied DB9-to-mini-stereo programming cable, and is
powered on then simply click on the Upload button
. Putting the VSA-31-SP into Operation
After you have successfully uploaded a configuration to the VSA-31-SP
Transmitter, disconnect the VSA-31-SP Transmitter from the computer
and power it off. Connect the VSA-31-SP Transmitter to the Receiver via
2 UTP (CAT5/5e/6) cables. Connect the User Interface to the Transmitter
via 1 CAT5 cable. When you connect power to the Receiver, you will see
the LED‟s on the User Interface flash twice and scroll, to indicate the boot
up sequence. If any of the optional settings have been enabled, those will
process first. Afterwards, the VSA-31-SP will now be ready to control the
projector by powering, select video inputs and adjust the volume.
