Projector Controller w/ Built-n VGA Splitter
3
D
escription
The Model HR-3P is a programmable serial device with 3 video inputs VGA, Composite
Video (CV) and S-Video (Y/C). The VGA input supports all PC resolutions to 1600x1200 and
the TV video inputs are NTSC, PAL, and SECAM compliant. The unit has a VGA splitter with
2 VGA outputs, but the CV and S-Video have only one output each (pass through). The
HR-3P can detect video on any of the inputs and issue preprogrammed serial commands
via its RS-232 port. It also features 1 discrete (digital or contact closure) input and 1
discrete output. The discrete input can be used to issue commands on its high-to-low, and
low-to-high transitions. The unit also keeps track of ON/OFF state of the projector and
outputs a TTL (hi/lo digital) signal on its discrete output line for controlling other external
devices such as lowering and raising a screen. The HR-3P is an ideal tool for the
automation of a projector.
The commands sent to the projector can be any ASCII (or non-ASCII) data with
programmable delays embedded in the string.
Hall Research Technologies, Inc. provides a powerful Windows™ based application that is
used to create the data files and upload it to the HR-3P.
Features
1. Compact, Rugged, Reliable, and Economical
2. High Resolution VGA Distribution amp can drive cables to 150 feet on outputs
3. Wide bandwidth supports resolutions to 1600x1200 at any refresh rate
4. Up to 8 user-programmable Command Strings
5. Allows multiple instances of user-defined delays within each string
6. Detects video on any input , or no video at all
7. Digital (discrete) input and output on screw terminals
8. Intuitive Operation
9. Comes with Windows™ software for programming
10. Made in USA
How to Obtain the Windows® Programming Software
The GUI (Graphical User Interface) needed to program the HR-1P can be downloaded at:
http://www.hallresearch.com/page/Products/HR-3P
Setup to Program HR-3P
1. Connect the provided power supply to the power port on the back right side of
the device.
2. Connect a crossover serial cable (provided) from a PC to the HR-3P.
3. Install the HR-3P Programmer software on the PC.
