VGA / HDTV Video Processor
7
OSD
H-POSITION – Adjust horizontal position of the OSD on the screen.
Range =
0-100%, default=10
V-POSITION – Adjust vertical position of the OSD on the screen. Range = 0-
100%, default=90
TIMER – Select the approximate number of seconds for the OSD to be
displayed on the screen before turning off.
Range = 0-100, default=10
BACKGROUND – Changes opacity of the OSD background on the screen. “0”
is a black background, “100” is a transparent background.
Range = 0-100%,
default=10
EXIT – Exit OSD Submenu
Factory Reset
Select this option to reset all values to the factory defaults.
Information
Displays source type, Input resolution, output resolution and firmware version.
Mirror
If enabled; this function will flip the image horizontally on the screen.
Range =
ON or OFF, default=OFF
Exit
This selection will exit the OSD Menu.
