Model SC-VGA-2B
6
COLOR
RED – Adjust RED RGB value.
Range is 0-100%, default=47 (RGB) or 48
(YPbPr)
GREEN – Adjust GREEN RGB value.
Range is 0-100%, default=47 (RGB)
or 48 (YPbPr)
BLUE – Adjust BLUE RGB value.
Range is 0-100%, default=47 (RGB) or 48
(YPbPr)
EXIT – Exit COLOR Submenu
SIZE
Select this option to toggle between FULL, PANSCAN, LETTERBOX,
UNDERSCAN or OVERSCAN display modes. The change occurs as each
option is selected.
Default=FULL
SOURCE
AUTO – Automatically detects the type of input video source based on the
selected resolution.
Default
PC – Forces the input video source to be RGBHV
YPbPr – Forces the input video source to be YPbPr
OUTPUT
Use arrows to adjust output mode. Refer to Section 5.2 below for a list of all
available modes.
The default output resolution of the SC-VGA-2B is XGA @ 60Hz.
The unit has non-volatile memory and memorizes all your settings before
power off and recalls those settings on the next power on.
At any time, pressing the UP ARROW ▲ and MENU button together will
change the output resolution to XGA@60Hz. Pressing the MENU and DOWN
ARROW ▼ together will change the output resolution to 480P@60 Hz.
