11
8x2 Video Matrix Switch
5. Specifications
Standards: VGA, SVGA, XGA, or XGA-2 video
Interfaces: Video: VGA; Keypads: EIA/TIA RS-232 Serial
Compliance: CE (meets requirements); FCC Part 15 Subpart B Class
A (meets specs),
Supported
Video Types:
RGBHV (VGA, SVGA, XGA, or XGA-2), RGBS, or RGsB (“sync
on green”)
Resolution and
Refresh Rate:
Up to 1600 x 1280 non-interlaced at up to 85 Hz
Bandwidth: DC to 265 MHz
Video Level: 0.7 volts peak-to-peak
Video Gain: 1-to-1 (buffered); for distances over 100 ft. (30 m), can be set to
proportionally apply higher gain to higher signal frequencies to
compensate for losses in cable
Maximum
Distance:
Up to 300 ft. (90 m) of total cable length from any attached CPU or
other input device to any attached monitor or other output device
User Controls: (2) 10-button switching keypads, (1) for each output; (2) Rear-
mounted 8-position DIP switches—(1) for each output port—for
distance compensation
Indicators: (16) Rear-mounted LEDs, (2) for each video-source port; (10) LEDs
on each keypad
Connectors: Front-mounted: (8) HD15 female for video input;
Rear-mounted:
(2) HD15 female for video output
(2) DB9 female for keypad input,
(1) 5-pin DIN female power inlet
Max Altitude: 10,000 ft. (3048 m)
Temperature Operating: 0 to 50°C; Storage: –40 to +85°C
Humidity: Up to 95% noncondensing
Enclosure: Steel
MTBF: 300,000 hours (calculated estimate)
Power: From utility-power (mains) outlet, through included detachable output
cord and external universal power supply:
Input: 100 to 240 VAC at 50 to 60 Hz (autosensing);
Output: +5 VDC at 1 A, +12 VDC at 0.5 A and –12 VDC at 0.5 A;
Consumption: 5 VA (5 watts) maximum
Size: 1.5"H x 12.1"W x 4.1"D (3.9 x 30.8 x 10.4 cm); mounting ears
protrude an additional 0.9” (2.2 cm) wide on each side
Weight: Net: Switch itself: 2.3 lb. (1 kg);
Keypads: 1 lb. (0.5 kg) each; Power supply: 1.3 lb. (0.6 kg);
Shipping: 6.7 lb. (3 kg)
