4

HDMI™ over Dual UTP Extender

Connect the display directly to the source and make sure you can get a picture without the

extender. If so then using the menus of the video source try to set the output resolution to a

low one (such as 480p) to start with. Insert the extender and verify that you get an image, if

so; then set the resolution to the next higher value (such as 720p). Continue this process

until you get the highest possible resolution without loss of image or audio.

3.1 Contacting Hall Research

If you determine that your extender is malfunctioning, do not attempt to repair the unit. The unit

contains no user serviceable equipment. Opening the unit will void the warranty. Contact the Hall

Research Technical Support department at 714-641-6607 or [email protected] to obtain a

RMA (Return Authorization) number.

Before you do, make a record of the history of the problem. We will be able to provide more efficient

and accurate assistance if you have a complete description.

4. Specifications

Supported Resolutions: PC from VGA to WUXGA, HDTV from 480i to 1080p
Max Cable Length:

Using Cat6: 130 ft (40m) at 1080p, 170 ft (52m) at 1080i or below

Dimensions:

2.6 x 2.6 x 1.1 inch (66 x 66 x 28 mm)

Enclosure:

Black Plastic ABS-94VO, UL File#56070

Weight:

0.5 Pounds (225 g)

Input Power:

5v DC at 2A max.

Operating

Temperature:

0 ~ +50 °C

Storage

Temperature:

-10 ~ +70 °C
