Mini-Cat® Brand HDMI™ Extender
3
1. Introduction
1.1 General
Thank you for purchasing a Mini-Cat ® brand HDMI™ on Catx (Unshielded Twisted Pair)
extender. These compact extenders are compliant with HDBaseT™ standard and can
extend DVI or HDMI™ signals to 230 or 330 ft depending on the Model number.
This User’s Manual applies to the following extenders:
UH1-BT HDMI™ on Single UTP Extender with HDBaseT-Lite™ to 230 ft
UH-1BTX HDMI™ on Single UTP Extender with HDBaseT™ to 330 ft
The extenders are comprised of a sender (-S) and a receiver (-R) and extend all PC
and HD resolutions without compression easily and reliably. Since the extenders are
compliant with HDBaseT™, they can be connected to any other HDBaseT™ compliant
device including sources or sinks that support the format.
The HDBaseT™ and HDBaseT-Lite™ products differ only in the maximum distance of
the cable; otherwise, they are fully identical in form and function. The UH-1BT and UH-
1BTX Sender and Receivers are also compatible with each other (you can connect BT
and BTX senders and receivers; however the maximum distance achievable is dictated
by the lowest of the two – 70m).
The extenders are HDCP compliant with pass-thru EDID, support embedded audio,
Full HD, deep color (1080p@60Hz @ 48 bits/pixel), and 3D video. They can also be
used to extend 4Kx2K video that is gaining popularity.
As a leader in the field of video over twisted pair extension, Hall Research’s Mini-Cat ®
brand has set a new standard in the industry for unsurpassed quality and reliability.
1.2 Features
 Extend HDMI or DVI over single Cat 5e/6 up to 330 or 230 ft (100 or 70 m)
 Utilizes HDBaseT™ extension technology
 Full HD support 1080p deep color, 3D, and 4K x 2K
 HDCP Compliant with pass-thru EDID from sink (display) to source
 Compatible with virtually all HDTV and PC resolutions
 Supports HDMI™ Audio
 Uncompressed digital video extension guarantees 100% fidelity
 Can connect to all HDBaseT™ and HDBaseT-Lite™ compliant products
 Reliable trouble free operation
 Plug and Play, no user configuration required
 Sturdy and compact metal enclosures with mounting provisions
 Locking HDMI Connector
 Universal Power Supplies included
 100% designed and manufactured in USA
