MODEL EMX-DVI EXTENDER & EDID MGR
1
1. EMX-DVI Windows™ Software Installation
1.1. General
The EMX-DVI graphical user interface (GUI) is a software-based solution
capable of configuring any setting on one or more EMX-DVI devices connected
to the Windows PC via a valid USB connection(s).
All of the device features, and more, are accessible from the GUI. EDID files
can be exported or imported. The device is also capable of writing custom
EDID data back to compatible display devices.
1.2. Installation Prerequisites
 A PC with Windows XP™ OS or later
 USB port
 Microsoft™ .NET Framework 2.0 or later (most recent OS including Windows 7
and 8 typically include this and no action is required). If .NET Framework 2.0 or
later is not installed on your PC, the Microsoft™ website has free downloads
available.
1.3. Software Installation
 If an earlier version of this particular software was previously installed,
UNINSTALL the program first from either the Add/Remove Programs
section of the control panel or by running the previous installation’s
SETUP.EXE and selecting “remove application”.
 Install the software by executing the SETUP.EXE program from the
installation source directory
 Accept the default settings, but if you want to specify a particular
installation directory other than the default, you may do so.
 Once the VR-DVI software installation has completed, either
click the desktop icon or navigate the Start Menu to
Start -> Programs -> Hall Research -> EMX-DVI Extender
