GoDEX EZPi1000 series User Manual
Page 41
EZPi1000 User Manual
37
13. Put first the fixing plate and then the washer
on the antenna connector. Now secure
them with the nut.
14. Screw the antenna onto the antenna
connector. You can now adjust the angle
of the antenna as required.
15. Finally, replace the top part of the printer
housing and secure it on the underside of
the printer using the screws you removed
earlier.
【
Note 1
】
Once you have finished installing the Ethernet module, the command "^XSET,USBETHERNET,1"
must be sent to the printer to enable the Ethernet module. While the Ethernet module is
enabled, the USB port is disabled. To enable it again, send the command
"^XSET,USBETHERNET,0" to the printer.
【
Note 2
】
The wireless network must be configured via a network cable.
